PD-Series

Ground Fault Circuit Protection

SmartGuard is an equipment ground fault protection device

that functions as a standard high-quality Carling hydraulic/

magnetic circuit breaker, offering customized overload and

short circuit protection. In addition, this breaker senses

and guards against faults to ground using a state of the art

integrated circuit developed by Carling. This new technology

detects faults and when a fault occurs, the breaker trips and

an LED illuminates. The LED gives a clear indication that the

trip occurred as a result of leakage. This protection helps

prevent serious equipment damage and fire.

Features:

? Overload, short circuit and ground fault protection in a

single package

? Handle style actuators with optional “handleguard”

? Wiping Contacts - Mechanical linkage with two-step

actuation – cleans contacts, provides high, positive

Agency Certifications:

contact pressure & longer contact life

? A trip-free mechanism, a safety feature, makes it

impossible to manually hold the contacts closed during

overload or fault conditions.

? A common trip linkage between all poles, another safety

feature, ensures that an overload in one pole will trip all

adjacent poles.

? Front panel or DIN rail mounting options

? “State of the art ” integrated circuit developed by Carling

? Equipment leakage sensitivity from 10 to 100 milliamps

? Integral push-to-test button and LED “tripped” indicator

? Immediate reset after fault has been cleared

UL Standard 1077

UL Standard 943

CSA Certified

TUV Certified

Component Recognition Program as

Equipment Leakage Circuit Interrupter

and, Protectors, Supplementary (FTTJ2, File

E177510).

Tested as Ground Fault Circuit Interrupters

for Equipment Protection.

Component Equipment Leakage Current

Interrupter with Supplementary Protector,

under Class C22.2,No. 144-M91, FIle

LR47848-50

IEC 947-2 and appendix B: Circuit Breakers

incorporating Residual Current Protection.

Complies with waveform requirements of

IEC 1008-1, Type A.

Carling Technologies, Inc.

60 JOHNSON AVENUE ? PLAINVILLE, CT 06062-1177

PHONE: (860) 793-9281 ? FAX: (860) 793-9231

EMAIL: SALES@CARLINGTECH.COM ? WWW.CARLINGTECH.COM
